wooden pattern Embossing machine is widely used in solid wood door board,cabinet board,furniture board and the surface is pressed simulated wooden pattern.it is suitable for embossing soild wood board,MDF and plywood.
wooden pattern Embossing machine is widely used in solid wood door board,cabinet board,furniture board and the surface is pressed simulated wooden pattern.it is suitable for embossing soild wood board,MDF and plywood.
wooden pattern Embossing machine advantage:
1, Pattern roller uses good quality 45# steel.
2,Pattern roller uses independent electric heating system.
3,Pattern roller diameter is 320mm,and the surface is electroplated.
4,Max. embossing width is 1220mm.
5,Embossing frequency control,1-15m/min
6,Processing thickness 1-150mm
7,Patten depth 0.1-1.2mm
wooden pattern Emabossing machine Specifciasstion:
| model number | GL650S/A | GL850S/A | GL1000S/A | GL1300S/A |
| Max.feeding size | 650*150MM | 850*150MM | 1000*150MM | 1300*150MM |
| pattern depth | 0.4-0.5MM 0.5-0.7MM 0.8-1.2MM | 0.4-0.5MM 0.5-0.7MM 0.8-1.2MM | 0.4-0.5MM 0.5-0.7MM 0.8-1.2MM | 0.4-0.5MM 0.5-0.7MM 0.8-1.2MM |
| motor power | 5.5KW | 5.5KW | 5.5KW | 7.5KW |
| heating motor power | 24KW/12KW | 24KW/12KW | 24KW/12KW | 24KW/12KW |
| embossing speed | 0-20M/MIN | 0-20M/MIN | 0-20M/MIN | 0-20M/MIN |
| dimension | 1430*1350* 1580MM | 1430*1350* 1780MM | 1430*1350* 1930MM | 1430*1350* 2280MM |
| mahcine weight | 1000KG | 1300KG | 1600KG | 2100 |
