5ft double side plywood glue spreader machine

this 5ft double side glue plywood glue spreader machine. it can coat glue on plywood double side at one time.

GEELONG produce different type plywood glue spreader machine.

this is 5ft double side plywood glue spreader machine. it is suitable for plywood or veneer glue coating.

it can cost the glue on plywood or veneer double sides per time.

GEELONG plywood glue spreader rubber roller using Corrosion resistant natural rubber.

the plywood glue spreader Rubber hardness is 55 degree.

the steel roller Use electroplating to prevent corrosion


5ft double side plywood glue spreader machine specification:

Roller quantity:4pcs

Working speed:24-90m/min

Diameter of glue coating roller: 246mm

Length of glue coating roller:1400MM

rubber thickness:13mm

Diameter of glue squeeze roller:217mm/410mm

Length of glue squeeze roller: 1400mm

Reducer:2 cycloidal pin

Power of motor: 3kw

Max. Veneer thickness: 20mm

Max. Veneer width: 1400mm

Overall size:2100*1300*1400MM

Machine’s weight: 1000KGS
