Glue spreader is important plywood machine. it is used to coat the glue on plywood uniformly.improve the plywood quality and save glue using volume.
GEELONG produces 4ft,5ft,8ft and 9ft glue spreader machine. glue spreader machine has normal type and penumatic type.
Glue spreader machine has double side and single side.
the rubber roller diameter of glue spreader has 246mm,305mm and 410mm.
Glue spreader machine can be customized accoding to client's requirement.
below is 2700mm glue spreader machine specification:
Diameter of glue coating roller: 310mm
Length of glue coating roller: 2700mm
Diameter of glue squeeze roller: 270mm
Length of glue squeeze roller: 2700mm
Power of motor: 5.5kw
Max. Veneer thickness: 30mm
Max. Veneer width: 2700mm
Overall size: 3500x1250x1400mm
Machine’s weight: 1500KGS
